Product Overview
Every smart home has a brain, and this is it. The IoT Gateway Mainboard PCBA (MT7628) is a powerful WiFi router gateway board built on the MediaTek MT7628 chipset and also the central node where all your devices meet.
Brightlx produces IoT gateway PCBA boards, WiFi router modules, smart home hub boards, and edge computing gateway modules for smart home and commercial IoT applications. The MT7628 platform runs OpenWrt-based firmware with Ethernet routing, hardware NAT for full-speed WAN-to-LAN throughput, and expansion support for Zigbee, BLE, and LoRa radios via mini-PCIe or USB interfaces. 4G/LTE modem options enable cellular backup connectivity, and edge computing versions support local automation, MQTT brokers, and Node-RED / Docker container deployment, making these boards ideal for smart home controller boards, WiFi router PCBA modules, IoT hub gateway boards, and industrial IoT gateway modules.
From custom PCB design for a new IoT gateway, through custom PCB assembly for production runs, to full turnkey manufacturing from SMT assembly to product assembly, Brightlx provides customized PCBA solutions, OEM services, and 100% functional testing with RF and Ethernet throughput verification on every outgoing board. We are your one-stop partner for IoT gateway boards and wireless modules.
Product Details
Key Features
MediaTek MT7628 MIPS 24KEc processor (580MHz)
WiFi 802.11 b/g/n (2.4GHz, 150Mbps)
5-port 10/100Mbps Ethernet switch (WAN/LAN)
RS232 / RS485 / UART serial communication
High processing power for gateway applications
Rich peripheral interfaces (USB, GPIO, SPI, I2C)
64MB DDR2 + 8-32MB Flash (configurable)
USB 2.0 host port for peripheral expansion
Technical Specifications
Processor | MediaTek MT7628 (MIPS 24KEc, 580MHz) |
Wireless | WiFi 802.11 b/g/n (2.4GHz), 150Mbps |
Ethernet | 5-port 10/100Mbps switch (configurable WAN/LAN) |
Serial Ports | UART / RS232 / RS485 (configurable) |
Memory | 64MB DDR2 RAM + 8-32MB SPI Flash |
PCB Type | FR-4, 4-layer |
Certifications | CE, RoHS, FCC, RED |
Main Components
MT7628 SoC, DDR2 RAM, SPI Flash, Ethernet PHY (RTL8306/RTL8201), network transformer, RJ45 connectors with LEDs, serial interface ICs (MAX485/MAX232), USB port, antenna connectors, DC-DC power supply
