Product Overview
The IP Camera / NVR System PCBA is a complete video surveillance solution for security and CCTV applications, covering residential and commercial security systems.
The boards feature H.264/H.265 encoding, PoE support, and AI person detection, spanning IP camera main boards, NVR recorder modules, WiFi camera boards, video processing boards, and video doorbell modules for complete surveillance system builds.
Brightlx is an ISO 9001 certified PCBA manufacturer with strict quality control throughout production. From custom PCB design for a new security camera and production batch assembly to full turnkey manufacturing, we support security brands and system integrators from first sample to volume production.
Product Details
Key Features
Professional image signal processor (ISP)
H.264 / H.265 (HEVC) video encoding
Multiple camera input support (NVR version)
Network video recording (NVR functionality)
Ethernet / WiFi network connectivity
AI smart detection options (optional)
ONVIF protocol compliance
SD card / SATA HDD storage support
Technical Specifications
Processor | HiSilicon / Goke / Ingenic (configurable) |
Video Encoding | H.264 / H.265 (HEVC) compression |
Resolution | 1080P / 3MP / 4MP / 5MP / 4K (configurable) |
Camera Inputs | 1-32 channels (NVR version) |
Network | Ethernet 10/100/1000Mbps + WiFi (optional) |
PCB Type | FR-4, 4-6 layer |
Certifications | CE, RoHS, FCC, ONVIF compliant |
Main Components
ISP SoC (HiSilicon/Goke/Ingenic), DDR RAM, SPI/NAND Flash, Ethernet PHY, RJ45 connector with magnetics, video encoder/decoder, audio codec, WiFi module (optional), SD card slot, SATA connector (NVR), power management IC, SMD passive components
