Product Overview
This high-power switching power supply (SMPS) PCBA is a highly reliable AC-DC converter module designed for industrial and commercial applications. As a custom SMPS PCBA manufacturer, Brightlx produces a wide range of power supply boards, AC-DC modules, high-power LED driver boards, and industrial power PCBAs for sectors such as LED lighting, industrial equipment, and consumer electronics. Our designs cover power ratings from 30W to 300W using Flyback and LLC resonant topologies, support a wide input voltage range (90–305VAC), and offer 12V, 24V, and 48V outputs in either Constant Voltage (CV) or Constant Current (CC) modes. Standard features include comprehensive protection mechanisms (over-current, over-voltage, and short-circuit protection), with LED driver versions supporting 0-10V and DALI dimming. These boards comply with DOE Level VI and ErP energy efficiency standards, making them ideal for industrial power supplies, high-power LED drivers, switching converter PCBAs, and AC-DC adapter modules. Whether you require custom PCB design for a new SMPS project, mass-production PCB assembly, or a complete turnkey manufacturing service, we provide tailored PCBA solutions, OEM services, SMT assembly, and 100% functional testing, including Hi-pot and burn-in tests. Besides, free samples are available for qualifying projects. With ISO 9001-certified manufacturing capabilities, Brightlx is your trusted one-stop PCBA supplier for power supply boards and SMPS modules.
Product Details
Key Features
Wide universal input voltage range (85-265V AC)
High efficiency (>90%) with low standby power
Comprehensive protection features (OVP/OCP/SCP/OTP/OLP)
Compact high power density design
Stable and reliable output performance
Industrial-grade reliability and durability
Flyback / LLC / Forward topology options
Multiple output voltage options (5V/12V/24V/48V)
Technical Specifications
Input Voltage | 85-265V AC (50/60Hz) universal |
Output Voltage | 5V/12V/15V/24V/48V DC (configurable) |
Output Power | 50-500W (configurable per specification) |
Efficiency | >90% typical (model dependent) |
Topology | Flyback / LLC / Forward (application specific) |
PCB Type | FR-4, 2-4 layer |
Certifications | CE, RoHS, FCC, UL, CCC |
Main Components
PWM controller IC, power MOSFET, high-frequency transformer, optocoupler, diode bridge rectifier, filter capacitors (input/output), output inductor, feedback circuit, Y-capacitor, fuse, EMI filter
